IDROBENNE serie PFO

Kompakt och mångsidig grip, lämplig för hantering av skrotmetall, kommunalt avfall och lösa material.

Compact and versatile polyp grab, suitable for handling scrap metal, urban waste and loose materials.

Models

Description

“The” truck crane grapple

The very compact design of PFO orange peel grapples makes them the best solution for truck cranes, where dimensions and weight are the key points. These grapples can give many advantages on mini excavators, when it’s necessary to work indoors or to operate in confined spaces.

Interchangeable rotator options

The grapple’s innovative design allows the equipment to incorporate a rotation mechanism, both mechanical,  (free, 250° rotation) or hydraulic (motor for continuous rotation). In PFO grapples these devices are easily interchangeable, without any modification in the overall dimensions. So, when needed, a PFO grapple may be easily equipped with a different rotation device.

Versatility

Orange peel grapples are multi-tines gripping devices. Each tine is set in motion by a double-acting hydraulic cylinder. For that the jaws, or teeth, have a synchronized, but independent, movement of opening and closing. The number of  tines vary from four to six. This feature makes polyp grapples particularly suitable for the collection and handling of large quantities of bulk materials such as metal scrap, paper, tires drive, solid urban waste and firewood. They can be mounted on truck cranes, mini excavators, stationary cranes, hydraulic excavators and wheeled loaders.

Experience in construction and reliability.

More than thirty years experience in the industry, the most modern technical design programs and a careful assembly make Idrobenne’s hydraulic equipment a reliable and safe product. Construction and testing are carried out by highly qualified and experienced personnel. The design of the equipment is always "user friendly", to grant simple access during maintenance.  All wear parts are easy to reach and quickly replaceable.

High quality components.

All products are built using high-tensile Swedish steel for the structural parts and use wear plates (Hardox) for parts in contact with the handled materials, such as the blades of the buckets, the tines and the tips. The large diameter pins are made of special steel, hardened under heat treatment. The bushes are provided of an internal spiral for the distribution of grease. The entire production cycle is certified according to ISO 9001 standards.

Custom links.

Orange peel grapples, clamshell buckets, log grapples and similar attachments must be mounted on operating machines through a cardan link. This part allows free swinging in the four horizontal directions (so-called pendulum mounting). Idrobenne can manufacture and supply custom-made links for any operating machine such as truck cranes, excavators, material handlers and earth moving equipment.
